Wagner by Diversitech WG840469
Wagner by Diversitech WG840469 Multi-Horsepower Direct Drive Furnace Blower Motor, Totally Enclosed Enclosure, 1/3, 1/4, 1/5, 1/6 hp, 208/230 V AC, 60 Hz, 1 Phase, 48 Frame, 825 rpm Speed, Belly Band/Shaft Up/Down Mounting
| Amperage Rating | : | 2.8/2/1.7/1.5 A Full Load |
| Application Type | : | Condenser Fan Motors |
| Bearing Type | : | Ball |
| Dimensions | : | 5.59 in Dia x 10.292 in L |
| Enclosure Type | : | Totally Enclosed |
| Frame | : | 48 |
| Frequency Rating | : | 60 Hz |
| Horsepower | : | 1/3, 1/4, 1/5, 1/6 hp |
| Insulation Class | : | Class B |
| Mounting Type | : | Belly Band/Shaft Up/Down |
| Number of Speeds | : | 2 |
| Phase | : | 1 |
| Rotation | : | Reversible |
| Service Factor | : | 1 |
| Shaft Size | : | 1/2 in Dia x 5 in L |
| Speed | : | 825 rpm |
| Temperature Rating | : | 140 deg F |
| Type | : | Multi-Horsepower |
| Voltage Rating | : | 208/230 V AC |
This Wagner® WG840469 Multiple Horsepower Condenser Fan Motors, 208-230V, 825/2 Speed, 1/3HP MAX is specially designed to cover a range of applications. The condenser fan motor is electrically reversible and features high and low speeds.
Wagner by Diversitech, WG840469, Direct Drive Furnace Blower Motor, Multi-Horsepower, Condenser Fan Motors Application, 1/3, 1/4, 1/5, 1/6 hp, 208/230 V AC, 2.8/2/1.7/1.5 A Full Load, 60 Hz Frequency, 1 ph, 825 rpm Speed, 2 Speed, Totally Enclosed Enclosure, 48 Frame, 1/2 in Dia x 5 in L Shaft, Reversible Rotation, 1 Service Factor, Belly Band/Shaft Up/Down Mounting, 140 deg F, 5.59 in Dia x 10.292 in L Dimensions
- Ball bearing design allows for greater heat endurance, improved performance, increased reliability, and enhanced motor life
- Extended mounting bolts provides easier installation in cramped spaces and allows the installer to start the threaded mounting nut quickly and efficiently
