| Dimensions | : | 14.38 in L x 5 in W x 2.5 in H Rectangular/7.75 in L x 9 in W x 2.5 in H Square |
| Humidity Rating | : | 0 to 95% Non-Condensing |
| Interconnection Capability | : | 50 Units |
| Operating Temperature | : | -4 to 158 deg F |
| Power Source | : | 20 to 29 VDC, 24 to 120 VAC, 50 to 60 Hz |
| Sensor Type | : | Photoelectric |
| Series | : | InnovairFlex™ |
| Type | : | Watertight Low Flow |
| Visual Alert | : | Red |
| Wiring Type | : | 4-Wire Plug-In |
The InnovairFlex™ series are the only duct smoke detectors flexible enough to fit configurations from square to rectangular and everything in between.
System Sensor® Duct Smoke Detector, Watertight Low Flow, Series: InnovairFlex™, 20 to 29 VDC, 24 to 120 VAC, 50 to 60 Hz Power Source, Photoelectric Sensor, 50 Units Interconnection, Red Visual Alert, 0 to 95% Non-Condensing Humidity, 4-Wire Plug-In Wiring, -4 to 158 deg F Operating, 14.38 in L x 5 in W x 2.5 in H Rectangular/7.75 in L x 9 in W x 2.5 in H Square Dimensions
- UV resistant, UL listed housing and cover material
- 4-wire photoelectric, integrated low-flow technology
- Air velocity rating from 100 to 4000 fpm (0.5 to 20.32 m/s)
- Plug-in sensor offers superb false alarm immunity and the latest sensor technology
- Increased wiring space with a newly added 3/4 in conduit knockout
- One easy access test/reset button and improved LED status
- New high contrast terminal designations
- Built-in short circuit protection from operator wiring errors
- Field selectable settings for configuring the detector
- 2 DPDT form-c relay contacts
- Backward compatibility with existing Innovair products, including remote accessories
