NuTone® AEN80F1

NuTone® AEN80F1 Flex Exhaust Fan, 80 cfm Flow Rate, 4 in Dia Duct, 26.9 W, 120 V, 0.3 A, 0.7 sones

Manufacturer: Broan-NuTone
Brand Name: NuTone®
Part#: AEN80F1
MPN: AEN80F1
Min. Order Qty: 1
Login for Availability
Login for Price
Color      :      White
Current/Amps      :      0.3 A
Duct Diameter      :      4 in
Flow Rate      :      80 cfm
Frequency Rating      :      60 Hz
Grille Length      :      11.5 in
Grille Material      :      Polymeric
Grille Width      :      12 in
Housing Height      :      5-3/4 in
Housing Length      :      9-1/4 in
Housing Material      :      Galvanized Steel
Housing Width      :      10 in
Humidity Sensing      :      No
Motion Sensing      :      No
Mounting Type      :      Ceiling
Series      :      Flex
Sones      :      0.7 sones
Voltage Rating      :      120 V
Wattage Consumption      :      26.9 W

NuTone®, AEN80F1, Exhaust Fan, Series: Flex, 80 cfm Flow Rate, 4 in Diameter Duct, 120 V, 0.3 A Current/Amps, 60 Hz Frequency, 26.9 W Wattage Consumption, 0.7 sones, 11.5 in Grille Length, 12 in Grille Width, Polymeric Grille, 9-1/4 in Housing Length, 10 in Housing Width, 5-3/4 in Housing Height, Galvanized Steel Housing Material, Ceiling Mounting, No Humidity Sensing, White

  • Effective ventilation to remove moisture and reduce the risk of mold or mildew in most full baths
  • Trueseal damper technology reduces air leakage up to 50%
  • Ezduct connector can be installed from the room side, with no attic access required
  • Powerful enough for rooms up to 75 sq.ft
  • Permanently lubricated ac motor engineered for continuous operation
  • Testing reflects total fan housing airtightness
