| Amperage Rating | : | 7.5 A |
| Connection Size | : | 1/2 x 1/4 x 3/8 in |
| Displacement | : | 7 cfm |
| Horsepower | : | 1/2 hp |
| Material | : | Aluminum |
| Maximum Vacuum | : | 15 micron |
| Motor Type | : | Capacitor Start |
| Oil Capacity | : | 21 oz |
| Overall Length | : | 14-1/2 in |
| Series | : | Platinum™ |
| Type | : | 2-Stage |
| Voltage Rating | : | 115 V AC |
JB Industries' PLATINUM® series vacuum pump is the best pump in the industry. Designed for the serious air conditioning and refrigeration technician, the PLATINUM® vacuum pump features a gas ballast and blank off valve. American made and subjected to JB's rigorous performance standards, the PLATINUM® Series is the top of the line for both quality and durability. Backed by an unprecedented 24 month over-the-counter warranty, there is no better pump on the market. Because each PLATINUM® pump is made at our facility in Aurora, Illinois, quality and dependability are woven in with hard working American pride. Completely field repairable, our PLATINUM® series is designed to last.
JB Industries Vacuum Pump, 2-Stage, Series: Platinum™, 115 V AC, 7.5 A, 1/2 hp, 15 Microns Maximum Vacuum, 7 cfm Displacement, 1/2 x 1/4 x 3/8 in, 21 oz Oil, Capacitor Start Motor, 14-1/2 in Overall Length, Aluminum
- 1/2 hp, 1725/1425 rpm capacitor start motor with thermal overload protection
- Gas ballast increases and keeps oil cleaner
- Check valve prevents oil back flow during power failure
- Low profile rocker switch
- Lift ring to hoist
- Tethered safety cap prevents oil spills during transport
- 1/2 in NPT break resistant handle encompasses exhaust
- Lighter weight finned aluminum housing reduces heat during operation
- Well-protected drain valve sealed with O-ring to prevent leaks
- All metal construction including all brass fittings
- Completely field repairable
