Genteq® 6510VUI

Genteq® 6510VUI 12-Pole Fan and Blower Motor, OAO Enclosure, 1 hp, 120 to 240 V, 60 Hz, 1 Phase, 48 Frame, 1050 rpm Speed, Round Mounting

Manufacturer: Regal Rexnord
Brand Name: Genteq®
Part#: 6510VUI
MPN: 6510VUI
Min. Order Qty: 1
Sold As: EACH
Login for Availability
Login for Price
Add / Remove CPN
Amperage Rating      :      12.8/7.4 A
Bearing Type      :      Ball
Enclosure Type      :      OAO
Frame      :      48
Frequency Rating      :      60 Hz
Horsepower      :      1 hp
Insulation Class      :      Class B
Mounting Type      :      Round
Number of Speeds      :      1
Phase      :      1
Rotation      :      CCW/CW
Service Factor      :      1
Shaft Size      :      0.500 in
Special Features      :      12-Pole
Speed      :      1050 rpm
Temperature Rating      :      40 deg C
Type      :      12-Pole
Voltage Rating      :      120 to 240 V

Genteq®, 6510VUI, Fan and Blower Motor, 12-Pole, 12-Pole Special Features, 1 hp, 120 to 240 V, 12.8, 7.4 A, 60 Hz Frequency, 1 ph, 1050 rpm Speed, 1 Speed, OAO Enclosure, 48 Frame, 0.500 in Shaft, CCW/CW Rotation, 1 Service Factor, Round Mounting, 40 deg C, Insulation Class: Class B

  • Electronically Commutated (ECM)
  • Full stainless steel exterior promotes resistance to water and chemical corrosion
  • Double sealed bearings extend the lifetime of the motor by combating early signs of bearing failure
  • Stainless steel output shaft seals protect against external contaminants
  • Insulation systems deliver superior protection against voltage spikes
  • Operational at 208-230/460 V at 60HZ
  • 1/2 in Diameter Shaft with flat Leads
