Gates® by Mars® A59

Gates® by Mars® Truflex® 74200 Fractional Horsepower Wrapped V-Belt, 4L Section, 1/2 in W Top, 61 in L Outside, 0.31 in THK

Manufacturer: Mars
Brand Name: Gates® by Mars®
Part#: A59
MPN: 74200
Min. Order Qty: 1
Sold As: 40/CS
Login for Availability
Login for Price
Add / Remove CPN
Outside Length      :      61 in
Section Size      :      4L
Temperature Range      :      -30 to 140 deg F
Thickness      :      0.31 in
Top Width      :      1/4 in
Type      :      Fractional Horsepower

Gates® Truflex® belts offer improved performance on light duty, fractional horsepower (FHP) V-belt drives. Their unique patented construction provides smooth, quiet operation with less vibration.

Gates® by Mars® Truflex® Wrapped V-Belt, Fractional Horsepower, 4L Section, 1/2 in Top Width, 61 in Outside Length, 0.31 in Thickness, -30 to 140 deg F

  • Gates® curves provide proper cord support and full contact with the sheave-groove for uniform loading, uniform wear and increased belt life
  • Flex-bonded cords are strongly bonded to the body of the belt resulting in equal load distribution and the absorption of bending stress without cord reduction
  • Flex-Weave® Cover is a patented fabric construction for longer cover life, providing extended protection to the belt core from oil, dirt and heat
  • Meets RMA static conductivity requirements
  • Meets RMA oil and heat resistant standards
  • ARPM number: 4L610
