Armstrong Air® QGA036S4DW1Y
Armstrong Air® 1.603342 Q Series™/QGA Standard Efficiency Gas Heating/Electric Cooling Packaged Unit, 3 ton Nominal, 54000 Btu/hr Input/43740 Btu/hr Output Heating, 81 % AFUE, 230 VAC, 3 ph, 11.5 EER
| AFUE Rating | : | 81 % |
| Coil Type | : | Aluminum Fin |
| Control Type | : | Electronic Blower |
| Cooling Capacity | : | 34000 Btu/hr Net/35000 Btu/hr Gross |
| Dimensions | : | 56-1/8 in W x 47-5/8 in D x 44-7/8 in H |
| Domestic/Import | : | Domestic |
| Drive Type | : | Direct |
| EER Rating | : | 11.5 |
| Flow Rate | : | 1200 cfm |
| Frequency Rating | : | 60 Hz |
| Heat Input | : | 90000 Btu/hr |
| Heating Capacity | : | 54000 Btu/hr Input/43740 Btu/hr Output |
| Low NOX | : | Yes |
| Material | : | Steel |
| Motor HP | : | 3/4 hp Blower, 1/3 hp Fan |
| Motor RPM | : | 825 rpm Fan |
| Nominal Capacity | : | 3 ton |
| Number of Phases | : | 3 |
| Power Rating | : | 2.8 kW |
| Refrigerant Type | : | R-410A |
| SEER Rating | : | 14 |
Armstrong Air®, 1.603342, Gas Heating/Electric Cooling Packaged Unit, Standard Efficiency, Series: Q Series™/QGA, 3 ton Nominal, 34000 Btu/hr Net/35000 Btu/hr Gross Cooling, 54000 Btu/hr Input/43740 Btu/hr Output Heating, 230 VAC, 3 ph, 60 Hz Frequency, 2.8 kW Power, 81 % AFUE, 11.5 EER, 14 SEER, Low NOX: Yes, Aluminum Fin Coil, R-410A Refrigerant, 90000 Btu/hr Heat Input, 35 to 65 deg F, 1200 cfm Flow Rate, Electronic Blower Control, Direct Drive, 3/4 hp Blower, 1/3 hp Fan Motor, 825 rpm Fan, Steel, 56-1/8 in W x 47-5/8 in D x 44-7/8 in H Dimensions, Domestic
- Accommodates both horizontal and downflow applications
- No special rigging or brackets required for placement
- Side and bottom connection entrances
- Base rails with forklift slots
- Quick connect electric connections
- Factory installed float switch
- Easy-to-install, plug-and-play accessories that do not require disassembly
- ECM Blower Motor
